Photo Contact Type Tachometer Speedometer DT2236B

This Hand Held Digital Tachometer accurately measures rotational speed (RPM) handly. With the rugged construction, portability and outstanding features make it an ideal choice for maintenance personnel, machine operators or others in a wide variety of machinery and material handling applications.

Features:

• Big / Clear 18mm LCD Screen
• Accuracy: ±(0.05%+1 digit)
• Sampling Time: 0.8sec (over 60RPM)
• Range Select: Automatic
• Memory: Max value, Min value, Last value
• Test Base: Quartz crystal
• Battery Power : 4x 1.5V AAA battery (not included)
• Detecting Distance: 50~250mm (LED)
• Detecting Distance: 50~500mm (Laser)
• Power Consumption: Approx 45mA (LED)
• Power Consumption: Approx 35mA (Laser)
• Measuring Range:
  Photo Tach: 2.5~99,999RPM
  Contact Tach: 0.5~19,999RPM
  Surface Speed: 0.05~1,999.9(m/min)
• Resolution:
  Photo Tacho: 0.1RPM(2.5~9,999.9RPM); 1RPM(over 10,000RPM)
  Contact Tacho: 0.1RPM(0.5~999.99RPM); 1RPM(over 10,000RPM)
  Surface Speed: 0.01m/min(0.05~99.99m/min); 0.1m/min (over 100m/min)
• Made in Taiwan
• Approx. size:  215 x 65 x 38mm

Package Content :

• 1 x Tachometer
• 1 x Manual
• 1 x Reflective Tape Mark (total 600 mm)
• 1 x Contact speed measurement fitting
• 3 x Contact rotational speed measurement fitting

(Note : Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time)
