- Brand by Victor
- Metallic screen board with stronger antimagnetic and anti-interferential function.
- New type holster, streamline design
- Inner test leads. It's very portable
- With unit symbol display, so more convenient to use
- High anti-jamming
- Large LCD makes the reading clearly
- Powered by 2 x 1.5V AAA batteries (Included)
|
Basic Function |
Range |
Basic accuracy |
|
DC Voltage : |
400m/4/40/400/600V |
±(0.5%+4) |
|
AC Voltage : |
400m/4/40/400/600V |
±(0.8%+6) |
|
Resistance : |
400Ω/4k/40k/400k/4M/40MΩ |
±(0.8%+4) |
|
Capacitance : |
4n/40n/400n/4u/40u/200uF |
±(3.5%+8) |
|
Frequency : |
100Hz/1000Hz/10kHz/100kHz/1MHz/10MHz |
±(0.5%+4) |
Specifications:
|
Special Function : √ |
|
|
Diode test : √ |
|
|
Continuity buzzer : √ |
|
|
Low battery indication : √ |
|
|
Data Hold : √ |
|
|
Auto power off : √ |
|
|
Function protection : √ |
|
|
Frequency : √ |
|
|
Duty cycle measuring : √ |
|
|
Input impedance : 10MΩ |
|
|
Sampling rate : 3 times/s |
|
|
AC Frequency response : 40~400Hz |
|
|
Operation way : Auto range |
|
|
Max. Display : 3999 |
|
|
LCD size : 55×43mm |
|
|
Battery : 3V (1.5×2) |
|
|
Product Dimension : 117×80×19mm |
|
- 1 x Meter
- 2 x Test leads
- 1 x User manual
- 1 x Holster
(Note : Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time)
